Value Range for
Bit 1
TWIN Mode

Value range for TWIN mode

Value Range for
Bit 0
Documentation
Mode

Value range for documentation mode

Value range for
Process control-
led correction
Process
Value range for process-dependent correction
Bit 0 Description
0 0 TWIN Single mode
0 1 TWIN Lead mode
1 0 TWIN Trail mode
1 1 Reserved
Description
0 Seam number of power source (internal)
1 Seam number of robot (Word 19)
Signal
Arc length stabili-
PMC zer
Value range
configuration
range
-327.8 to +327.7
SINT16 0.0 to +5.0 Volts 10
