3. CONNECTION DIAGRAMS

3.3. CONNECTION DIAGRAM FOR UNIT WITH BOOSTER PUMP

Black tube
Models
MO 5-50P
MO 5-75P
MO 5-100P
The manufacturer reserves the right to modify product design or specific components, if such
modification does not entail deterioration of consumer properties of the product.
36
Red tube
Code P0090636 - Rev 0 - 19/06/2019
220V
