2. MACHINE COMPONENTS AND FUNCTIONING

General characteristics

The machine has been designed and built to supply coffee, water and steam. It
has no grinder.
On the right side there is a compartment to insert the can of water and under the
rear part there are the connection for the water network and the valve to select
can or network.
The button on the front switches on the machine, whereas the display provides
information regarding time, boiler temperature, Eco status, standby, etc. Through
the machine wi-fi connection, direct setting is possible from other devices such
as smartphone, tablet or pc, using a URL code.
Inside the machine is located the boiler for heating water and steam and the
coffee boiler.
The parts that make up the machine are described below.
Legend:
a. Cup-warmer top
b. Hot water delivery lever
c. Steam delivery lever
d. Hot water delivery wand
e. Steam delivery wand
f. Pump gauge
g. Boiler pressure gauge
h. Machine ignition switch
i. Display
j. Coffee distribution lever
k. Coffee group
Dimensions l x h x p
Net weight
Power supply
Power
Working temperature
l. Filter holder
m. Table top for cups
n. Water can + pipe
o. Drip collection reservoir
p. Resting feet
q. Network can tap
r. Direct discharge reservoir
s. Pump pressure adjustment
t. Key
u. Network water connection
330 x 383 x h 490 mm
32 Kg
120/220-240 V/ 50-60 Hz
1550 W
+5° / +45° C
