MOD. 0835 - 02835 - 03035

4. DESCRIPTION OF COMPONENTS

1. Plug
2. ON/OFF switch with indicator light
3. Heating warning light
4. Coffee dispensing pushbutton
5. Steam switch
6. Coffee grinder starter button
7. Water tank
8. Backflow pipe
9. Suction pipe
10. Steam nozzle
11. Air mixer
12. Cup warmer cover
13. Cup grill
14. Dispensing unit
QUICK MILL
15. Filter Holder
16. One cup filter
17. Two cup filter
18. Filter holder support for grinding
19. Ground Coffee exit
20. Coffee presser
21. Hopper Lid
22. Removable hopper
(coffee bean container)
23. Hopper locking lever
(Mod. 0835)
24. Grinding Grade selector lever
25. Plate grade selector lever
26. Pump pressure gauge
27. Coffee doser rimer
(Mod. 0835)
(Mod. 02835 - Mod. 03035)
