Mod. 07000

1. DESCRIPTION OF COMPONENTS

1.1. A - Coffee bean container
1.2. B - Coffee bean container shutter
1.3. C - Ground coffee door
1.4. D - Drip tray
1.5. E - Drip tray warning light
1.6. F - Water tank
1.7. G - Coffee grounds container
1.8. H - Coffee dispenser nozzle
1.9. I - Coffee nozzle lift/lower adjustment
1.10. L - Hot water dispenser nozzle
1.11. M - Steam wand
1.12. N - Front door
1.13. O - Cup warmer tray
1.14. P - Display
1.15. 1 - Espresso dispenser key (key1) - decrease data in menu functions
1.16. 2 - Long coffee dispenser key (key2) - increase data in menu functions
1.17. 3 - Extra long coffee dispenser key (key 3)
1.18. 4 - Extra dispenser key (key 4)
1.19. 5 - Hot water dispenser key (key 5)
1.20. 6 - Steam dispenser key (key 6)
1.21. 7 - Ground coffee dispenser key (key 7) - in the menu function esc/cancels modification,
exits a menu or submenu
1.22. 8 - Menu access key (key 8) - in the menu function enter/confirms modification,
enters a menu or submenu
1.23. 9 - Machine on and off key (key 9)
