Promag 23 compact version

8.1 Replacing the transmitter
WARNING
L
The measuring device is energized!
Risk of fatal injury from electric shock.
‣
Open the measuring device only when the device is de-energized.
Remove the housing seal. When installing, use a new housing seal.
