Endress+Hauser Promag 10 Einbauanleitung Seite 14

Austausch messumformer
Vorschau ausblenden Andere Handbücher für Promag 10:
Inhaltsverzeichnis

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

EA00082D
6 →
Ø < 2 mm
9.2
Replacing non-Ex version of aluminum transmitter
Proceed as described in Section 9.1 →  13and as illustrated in the pictures below.
Special screw! Do not loosen the screw completely or replace it with another one. Only
use original parts from Endress+Hauser.
1 →
1.
7 Nm
(5.2 lbf ft)
Turn neck component and release
screws.
14
7 →
In Category II2GD and Div.1
devices for use in hazardous
areas, shielding plates are located
between the individual
electronics boards. Remove these
and insert them again when
installing.
2
2.
1.
8 mm
Turn the transmitter and lift it
off.
8
1.
2.
T20
2.
