Tools list

Slotted head
screwdriver
0.5 × 3.5 mm
7

Promag 800 compact version

7.1

Preparatory steps

7.1.1

Switching off the device

1. In the SmartBlue App: open system.
2. Open device management.
3. Open reset device.
4. Select switch off device.
5. Press OK to confirm.
 The device switches off and can be disconnected from the power supply without
data loss.
7.1.2 Switching off the power of the transmitter housing, compact version
1 →
T20
2.
‣
Loosen the Torx screws, open the
cover.
1. Devices powered by power unit: disconnect the device from the mains.
Endress+Hauser
Torx screwdriver
T10, T20
2
1.
‣
Open the display module, push the ribbon cable out of the holder,
disconnect the plug.
2.
EA01325D
3.
1.
