GROUP K -
149
Mb.SL.
diSAb.
EnAb.
150
sL.ad.
Select slave address for serial communication.
1...254
151
SL.b.r.
Selects baudrate for serial communication
1.2 k
2. 4 k
4.8 k
9.6 k
19.2 k
28.8 k
38. 4 k
57.6 k
115.2k
152
s.s.p.F.
Selects the format used by the ATR144 during modbus
RTU serial communication.
8-N-1
8-E-1
8-o-1
8-N-2
8-E-2
8-o-2
153
se.de.
Sets the serial delay
0...100
- Serial communication Slave
sL.S.P.
(only for ATR144-xxx-T)
Modbus Slave
Disabled
Enabled. (Default)
Slave Address
Default: 247
Slave Baud Rate
1200 bit/s
2400 bit/s
4800 bit/s
9600 bit/s
19200 bit/s (Default)
28800 bit/s
38400 bit/s
57600 bit/s
115200 bit/s
Slave Serial Port Format
8 bit, no parity, 1 stop bit (Default)
8 bit, even parity, 1 stop bit
8 bit, odd parity, 1 stop bit
8 bit, no parity, 2 stop bit
8 bit, even parity, 2 stop bit
8 bit, odd parity, 2 stop bit
Serial Delay
ms, Default: 5
User manual - ATR144 - 87
