If installation malfunctions, the controller switches off
the regulation output and reports the anomaly noticed.
For example, controller will report failure of a connected
thermocouple visualizing e-05 (flashing) flashing on display.
For other signals see table below.
E-02
SYSTEM Error
E-04
eeprom
Error
E-05
PRobe 1
Error
E-07
ser iaL error
E-08
SYSTEM Error Missing calibration
E-80
rfid Error
100 - ATR144 - User manual

Table of anomaly signals

Cause
Cold junction
temperature sensor
failure or environment
temperature out of
range
Incorrect configuration
data. Possible loss of
instrument calibration
Sensor connected
to AI1 broken or
temperature out of
range
Communication error
in modbus master
RFID tag malfunction
What to do
Call assistance
Verify that
configuration
parameters are
correct.
Control connection
with probes and
their integrity.
Check the
configuration
parameters and
the RS485 serial
connection
Call assistance
Call assistance
