GROUP B -
18
c.ou. 1
Selects the command output related to the process1
and the outputs related to the alarms.
c. o2
c. o1
c. SSr
c. vAL.
ATR144-AD
c. o2
c. o1
c. SSr
c. vAL.
ATR144-AD-T
c. o1
c. SSr
c. vAL.
19
Ac.t. 1
Action type to control process 1.
HEAt
cooL
20
c.HY. 1
Sets the hysteresis value used for process control
during ON/OFF functioning
-9999..+9999 [digit
sensors), Default: 0.2.
21
L.L.S. 1
Lower limit setpoint selectable for command setpoint 1.
-9999..+30000 [digit
sensors), Default: 0.
cmd. 1
Process 1
Command Output 1
Command on relay output Q2.
Command on relay output Q1. (Default)
Command on digital output.
Servo-valve command with open loop.
Command
Q2
Q1
DO1
Q1(open) Q2(close)
Command
Q1
DO1
Q1(open) DO1(close)
Action type 1
Heating (N.A.) (Default)
Cooling (N.C.)
Command Hysteresis 1
1 p. 101
Lower Limit Setpoint 1
1 p. 101
- Outputs and regulation
] (degrees.tenths for temperature
] (degrees.tenths for temperature
AL. 1 AL. 2
Q1 DO1
Q2 DO1
Q1 Q2
DO1 -
AL. 1
DO1
Q1
-
User manual - ATR144 - 61
