Pixsys ATR144 Installationsanleitung Seite 103

GROUP C - reG. 1 - Autotuning and PID 1
36 Tune 1
tun. 1
37 Setpoint Deviation Tune 1
s.d.t. 1
38 Proportional Band 1
p.b. 1
39 Integral Time 1
i.t. 1
40 Derivative Time 1
d.t. 1
41 Dead Band 1
d.b. 1
42 Proportional Band Centered 1
p.b.c. 1
43 Off Over Setpoint 1
o.o.s. 1
44 Off Deviation Threshold 1
o.d.t. 1
45 Cycle Time 1
c.t. 1
46 Cooling Fluid 1
co.F. 1
47 Proportional Band Multiplier 1
P.b.M. 1
48 Overlap / Dead Band 1
o.d.b. 1
49 Cooling Cycle Time 1
c.c.t. 1
50 Lower Limit Output Percentage 1
L.L.P. 1
51 Upper Limit Output Percentage 1
U.L.p. 1
52 Max Gap Tune 1
m.G.t. 1
53 Minimum Proportional Band 1
mn.p. 1
54 Maximum Proportional Band 1
ma.p. 1
55 Minimum Integral Time 1
mn. i . 1
56 Overshoot Control Level 1
o.c.L. 1
57÷61 Reserved Parameters - Group C
GROUP D - AL. 1 - Alarm 1
62 Alarm 1 Function
AL. 1 .f.
63 Alarm 1 State Output
A.I .5.o.
64 Alarm 1 Hysteresis
a. 1 .Hy.
65 Alarm 1 Lower Limit
A. 1 .L.L.
66 Alarm 1 Upper Limit
A. 1 .u.L.
67 Alarm 1 Reset
a. 1 .re.
68 Alarm 1 State Error
A. 1 .S.e.
69 Alarm 1 Led
A. 1 .Ld.
User manual - ATR144 - 103
63
63
64
64
64
64
64
64
65
65
65
65
65
66
66
66
66
66
66
66
67
67
68
69
69
69
69
70
70
70
