67
a. 1 .re.
Alarm 1 contact reset type (always autom. if AL. 1 .F. = c.
Aux).
A. rEs.
M. rEs.
M.rEs.S.
A. rEs.t.
68
A. 1 .S.e.
Alarm 1 output status in case of error.
If the alarm output is a relay:
open
CLose
If the alarm output is digital output (SSR):
off
on
69
A. 1 .Ld.
Defines the status of the led A1 in correspondence of
the related output
o.c.
c.c.
Alarm 1 Reset
Automatic reset (Default)
Manual reset (manual reset by SET key or
by digital input)
Stored manual reset (keeps the output
status also after a power failure)
Automatic reset with timed activation.
The alarm remains active for the time
set on the parameter A. 1 .de., even if the
conditions generating it are missing. To
be able to act again, the alarm conditions
must disappear.
Alarm 1 State Error
Contact or valve open. (Default)
Contact or valve closed.
Digital output OFF. (Default)
Digital output ON.
Alarm 1 Led
ON with open contact or DO switched off.
ON with closed contact or DO switched
on. (Default)
User manual - ATR144 - 71
