A2.2 Motor 45-DC-04
Motor data
Motor system
Rated voltage
Frequency
Speed range
Current
Torque
Output power
Temperature monitoring
*The maximum frequency and thus the maximum permissible speed depends on the ball bearing. The maximum permissible frequency/speed
of your spindle can be found on the rating plate, the data sheet or in chapter
Performance diagram
Torque power diagram water-cooled in connection with frequency inverter type e@syDrive 4638 and motor-choke
220 µH.
• Values only match for the setup described above.
• The mechanical loads must be complied with independent of the electrical ratings, and they must be
checked separately for each application.
• Information about the individual maximum mechanical loads should be requested from SycoTec.
Brushless DC motor (BLDC)
172 V
83 – 1,333 Hz
5,000 – 80,000 rpm
S1: 10.3 A max. 17 A-60s
S1: 24.5 Ncm max. 44.5 Ncm
S1: 2,000 W max. 3,700 W
PTC
3.2 Variant
21
overview.
