3 Technical description

• Further installation dimensions, with tolerances, are available on request from SycoTec.
• Applicable standard: EN 60034-1 "Rotating electrical machines".
• Technical data relates to operation with spindle cooling.
Deviations are to be agreed with SycoTec.
3.1

General technical data

Housing diameter
Bearing system
Motor system
Motor protection
Tool clamping system
Collet-chuck clamping range
Clamping type
Run-out (taper)
Tool change
Cable / Connector type
Weight
Collet stop (CS)
Taper cleaning (TC)
ESD
Protected against dirt and cooling lubricant
Protection category
Cooling system
Tool cooling
Housing material
Ambient conditions
Permitted in interior rooms
Ambient temperature
Relative humidity
Max. altitude
Storage and transport conditions
Ambient temperature (transport)
Ambient temperature (storage)
Relative humidity
Air pressure
Keep dry!
Technical modifications reserved.
Features of variants see:
Spindle dimensions see:
Detailed information about motor see:
45 mm
2 x hybrid, lifetime lubrication
Brushless DC motor (BLDC)
PTC
Direct shaft clamping system C5
max. Ø 6 mm (collet-chuck C5)
C5
≤ 1 µm
Pneumatic 4.0 bar or 6.0 bar (hose Ø 4 mm)
915
1.85 kg
✓
✓
optional
Sealing air 15-20 l/min@STP (hose Ø 4 mm)
IP 55
Cooling via clamping bracket
Integrated cooling channels for external tool cooling
6 spray nozzles
Stainless steel
5 – 40°C (41 – 104°F)
max. 80%
2,000 m
-30 – 60°C (-22 – 140°F)
0 – 40°C (32 – 104°F)
15 – 93%
700 – 1,060 hPa

3.2 Variant overview

A1 Dimensional drawings
A2 Motor overview
