A2 Motor overview

A2.1 Motor 45-DC-03
Motor data
Motor system
Rated voltage
Frequency
Speed range
Current
Torque
Output power
Temperature monitoring
*The maximum frequency and thus the maximum permissible speed depends on the ball bearing. The maximum permissible frequency/speed
of your spindle can be found on the rating plate, the data sheet or in chapter
Performance diagram
Torque power diagram water-cooled in connection with frequency inverter type e@syDrive 4626.
• Values only match for the setup described above.
• The mechanical loads must be complied with independent of the electrical ratings, and they must be
checked separately for each application.
• Information about the individual maximum mechanical loads should be requested from SycoTec.
Brushless DC motor (BLDC)
43 V
83 – 1,333 Hz
5,000 – 80,000 rpm
S1: 16 A max. 24 A-60s
S1: 12.4 Ncm max. 20.1 Ncm
S1: 1,015 W max. 1,370 W
PTC
3.2 Variant
20
overview.
