Components Filter Device
4.2 Sartocon Slice and Sartocube
®
Fig. 5: Sartocon Slice Self Contained
®
Pos . Description
1 Permeate port* with AseptiQuik
2 Permeate port* closed
3 Notch for lower guide rod
4 Feed with AseptiQuik
5 Retentate with AseptiQuik
6 Notch for upper guide rod.
* TC-Clamp connection (TC)
3
5
2
1
4
Fig. 6: Sartocube Self Contained
®
Pos . Description
1 Feed port with AseptiQuik
2 Retentate port with AseptiQuik
3 Permeate port with AseptiQuik
4 Notch for lower guide rod
5 Notch for upper guide rod
6 Carrying straps (to support weight during lifting and transportation)
12 Instructions for Use Sartocon
®
6
5
4
G ⅜" sterile connector
®
G ⅜" sterile connector
®
G ⅜" sterile connector
®
L 1" sterile connector
®
L 1" sterile connector
®
G ¾" sterile connector
®
Slice Self Contained | Sartocube
®
Self Contained with AseptiQuick
1
2
3
Self Contained
®
®
6
