7.2

Clamping Forces

7.2.1 Sartocon Slice Self Contained
®
Membrane Sartocon
Filter Holder
Required Clamping
Force
Hydrosart 10 – 14 kN
®
PES 14 – 17 kN
Sartocon Slice Self Contained Holder with Hydraulic Piston (12 .5 cm²)
®
Required Clamping Force,
Operating Conditions
Hydrosart 10 – 14 kN
®
PES 14 – 17 kN
7.2.2 Sartocube Self Contained
®
Sartocube Self Contained Holder, Hydraulic
®
Required Compression
Operating Parameters
Hydrosart 18 – 22 kN
®
PES 22 – 25 kN
Sartocube Self Contained Holder, Manual with Ball Bearing
®
Required Compression
Operating Parameters
Hydrosart 18 – 22 kN
®
PES 22 – 25 kN
* After every tenth time of use, the PEEK washers should be replaced. The bronze nut or the trapezoidal thread should be replaced as soon as
abrasion is visible. It is essential that the bronze nut and the trapezoidal thread are kept clean.
Slice
®
Required Torque
20 Nm
25 Nm
Instructions for Use Sartocon
Sartocon Slice filter holder with trapezoidal
®
thread, PEEK washers and bronze clamping nuts
Required Torque
17 Nm
17 Nm
Hydraulic Pressure,
Operating Conditions
80 – 115 bar | 1,200 –1,650 psi
115 – 140 bar | 1,650 – 2,000 psi
Hydraulic Pressure Operating Parameters
for Hydraulic Holder with 12.5 cm
150 – 170 bar | 2,175 – 2,465 psi
170 – 200 bar | 2,465 – 2,900 psi
Torque Applied with a Torque Wrench
Operating Parameters
60 Nm
80 Nm
Slice Self Contained | Sartocube
®
Technical Data
Piston
2
Self Contained 25
®
