10 | Operation
• Austroflamm GmbH accepts no liability or responsibility for the connection of our heating appli-
ances to shared exhaust pipes/chimneys – multiple occupancy. For more information consult a
chimney sweep and check your national, regional and local building regulations.
Electrical connection
1
Fig. 28: Electrical connection
10.2 Operating modes
10.2.1 Pellet operation
Fig. 29: Automatic ignition
Fig. 30: Pellet operation
30
EN
Your stove is designed for connection to a 230 V / 50 Hz
mains. The connection cable is included.
The mains socket connection (1) is located on the rear of
the appliance and is protected with a T2.5 A glass tube
fuse.
The power consumption of your appliance is visible on the
nameplate.
Automatic ignition
The stove can be started with the start/stop button on the
status display or heat output display.
As an option it can be started via IR remote control or via
the app. Ignition of the pellets is fully automatic and takes
place in several phases. These phases are shown on the dis-
play (riddling grate placement - combustion pot filling - ig-
nition phase 1 - firebox temperature build-up - ignition
phase 2 - ignition control - ignition phase 3 - release and
control by user - full fire phase).
Ignition is cancelled by pressing the start/stop button dur-
ing the ignition phase. An "E102" error message appears if
ignition is cancelled.
Pellet operation
In pellet operation, pellet quantity and combustion air are
supplied according to the set heat output.
The desired room temperature must be set in the room
temperature display. If this is reached, the stove automatic-
ally regulates to the lowest output level or switches OFF if
the ECO function is enabled (see Settings/ECO mode).
Pressing the stop button switches the stove into burnout
phase.
The current room temperature is measured using a cable-
attached temperature sensor on the back of the appliance.
In pellet operation, a fluctuating chimney draught or in-
creasing contamination of the exhaust gas pipes is automat-
ically balanced by the exhaust gas fan.
