Care And Cleaning; Disassembling The Appliance - Gastroback DESIGN FLEISCHWOLF ADVANCED Bedienungsanleitung

CARE AND CLEANING

WARNING: Never hold your face or other body parts over the feed chute when the
motor is running because little pieces of food could be thrown out of the feed chute.
Never put foreign substance or hard objects into the feed chute.
Before the mincer is used for the first time and after each use, all parts – with the excep-
tion of the motor housing – must be thoroughly cleaned in warm soapy water. In case of
blockage proceed according to the instructions in the ›Trouble shooting guide‹.

DISASSEMBLING THE APPLIANCE

WARNING: To avoid injury and damages of the appliance turn the appliance off
(by turning the control switch to STANDBY - picture A) and then wait for approx. 6
seconds to be certain that the motor is no longer running. Always pull the plug before
you start disassembling or cleaning the appliance.
1. Switch off the mincer and disconnect the power supply cable from the mains. Check
that the motor has completely stopped.
2. Take the pusher and the feed pan of the feed chute.
Note:
If the tools got stuck knock the mincer carefully on a stable cutting board. The grinding
disc should be facing up.
ATTENTION:
mincer.
6. Remove meat residues. Operate as described:
ATTENTION:
use abrasives for cleaning! This will cause discolouration and corrosion and damage the
motor.
7. Wash all parts thoroughly in warm soapy water. Do not use aggressive detergents.
38
3. Loosen the screw plug on the right side of the mincer by
turning it counterclockwise until you can take the worm
housing out of the motor housing without any resistance
(picture B).
4. Loosen the closing ring by turning it counterclockwise If
the closing ring is screwed on too tight you can use the
provided spanner to loosen the closing ring.
5. Take the closing ring of the worm housing and take the
accessories (worm, crossed-blade knife and grinding disc
or the sausage filling attachment and the adaptor disc)
out of the worm housing.
Be careful not to damage your bench top, the cutting board or the
Never put the motor housing or the accessories in the dishwasher or
