disc.
34
4. Mount the grinding disc on the knife. The arresting pin
must lock precisely into the corresponding recesses (pic-
ture F).
IMPORTANT:
If the tools overlap the edges of the worm
housing the worm is not placed all the way inside the worm
housing. Turn the worm a little bit to make it fit inside but do
not use force. If mounted correctly the grinding disc is visible
outside approx. 2 mm of the front of the worm housing and
the axis of the worm is visible outside 5 mm of the grinding
5. Firmly screw the closing ring on the worm housing and
tighten by hand by turning it clockwise (picture G).
ATTENTION:
Pay attention not to cant the screw. If the
screw cants the screw thread gets damaged.
ten the screw too much as this can cause damage
to the motor.
If the screw does not turn easily use the pro-
vided spanner for help and put some sunflower oil (or other
edible oil) on the screw before mounting.
6. Place the feed pan onto the worm housing and place the
pusher into the opening of the feed chute (picture H).
The appliance is ready for operation.
Do not tigh-
