To minimize chance of injury or death from rollover:
• Keep ROPS in the raised and locked position and use
the seat belt.
• Lower the ROPS only when absolutely necessary.
• Drive slowly and carefully. Raise the ROPS as soon as
clearance permits. Read and follow slope operation
instructions and warnings.
• Always fasten seat belt during operation of the machine
(mower equipped with ROPS in "raised/up" position).
• Inspect the area to be mowed for proper overhead
clearance (tree limbs, guy wires, doorways, etc.) Do not
contact any overhead object with the ROPS.
Always pull from the Zero Turn hitch. Do not attach chains
or ropes to the ROPS for pulling purposes, as the machine
can tip backwards.
3.6

ANTI-SCALP WHEELS

See figure 2
Anti-scalp wheel kits are standard on Cramer units. These
anti-scalp wheels are designed to minimize scalping when
mowing on rough, uneven terrain. After setting the cutting
height, adjust the anti-scalp wheels so they extend below the
deck but do not contact the ground. They should always be at
least 0.6 cm to 1.9 cm below the deck. With the unit sitting on
a flat level surface, the wheel position can be adjusted up or
down as needed from 1.9 cm to 4.4 cm below the blade
surface. Move the wheels up or down - using the different
axle mount holes in the wheel mount bracket (if applicable on
model).
3.7

NEUTRAL BYPASS KNOB

See figure 7-8
1. Locate the Neutral Bypass Knobs behind the frame at the
rear of the mower.
2. Remove the (4) thumb screws holding in the mesh cover.
3. Remove the neutral bypass knob from its original location
and install it to the motor. Operate one or both of the
knobs on the motor, as needed.
4. Rotate the neutral bypass knobs clockwise to release
drive brakes; counterclockwise to engage.
5. Install the neutral bypass knob(s) back to its/their original
location after completing maintenance.
Never drive mower with the neutral bypass knob working.
Always install the neutral bypass knob to the original
position before driving! Failure to re-install the knob could
cause serious damage to your mower and void mower
warranty!
WARNING
WARNING
WARNING
English
Never pull the neutral bypass lever outside when the
machine is working on the slope!
3.8 USE THE CONNECTIVITY
FUNCTION
The connectivity box software can provide the location and
data of the machine.
If the connectivity box is damaged or removed, the machine
will go into limp home mode in which the machine can only
be drived in low speed without the blade working.
4

OPERATION

4.1

BEFORE OPERATION

4.1.1 ADJUST THE STEERING CONTROL
LEVER
The steering control levers can be adjusted for operator
comfort. By loosening the cap screws that attaches the upper
control lever to the lower lever, the upper control lever can be
pivoted to fit the operator's personal preference. The steering
control levers should be adjusted so that they align with each
other when in the neutral position.
4.1.2 ADJUST THE SEAT
See figure 6
Make sure seat pan is securely bolted down prior to each
use to prevent seat from moving/tilting in the event of
mower tipping or rollover.
The seat can be adjusted forward and rearward by moving the
latch under the seat. Move the latch to left and pull the seat
where you have the best control of the machine and are the
most comfortable and then tighten the safety belt.
You can adjust the suspended pressure of the seat by turning
the cyclone float knob. Turn clockwise the preload will
increase and counterclockwise for the preload to reduce.
4.1.3 ADJUST THE DECK CUTTING
HEIGHT
See figure 9
Before using the mower, raise the deck height to the cutting
position best suited for your lawn.
Deck height is adjustable from 2.5-14 cm. Deck should be
raised while mowing is in progress to avoid stumps, rocks or
other obstacle that can be damage mower deck.
1. Stop the mower and disengage blades.
