Check the tire pressure carefully while inflating. Too much
air in the tire could cause the tire to burst, causing serious
personal injury.
7.3

LUBRICATION

Replace the gearbox oil after you operate the machine for
50 hours for the first time, then replace the oil every 500
hours.
Brand Gear-
box
82ZT132 SP600
7.4

TORQUE VALUES

Particular attention must be given to tightening the drive
wheel lug nuts and blade spindle bolts. Failure to correctly
torque these items may result in the loss of a wheel or blade,
which can cause serious damage or personal injury.
Torque values are given below:
Part
Wheel (lug) nuts
Blade spindle bolt 114-118
Lug nuts only -It is recommended that these be checked after
the first 2 hours of operation, initially, every 100 hours and
following removal for repair or replacement.
7.5

SEAT BELT MAINTENANCE

Inspect the seat belt system (all seat, seat belt parts, seat pan
and seat pan latch) daily prior to mowing for signs of any
damage. These parts should be replaced if any parts indicate
signs of:
• cuts
• fraying
• extreme or unusual wear
• significant discoloration due to UV exposure
• dirt or stiffness
• abrasion to the seat belt webbing
• damage to the buckle, latch plate or hardware
• any other problem
If the seat belt is to be cleaned, use soap and water. Do not
use carbon tetrachloride, naphtha, etc., as these will weaken
the webbing. For the same reason, do not bleach or dye the
webbing. Replace seat belt if worn or damaged.
WARNING
NOTE
Moto Gearbox Oil
type ratio quantity
AC 32 0.6L
WARNING
Ft-lbs. Nm
83-118 112-132
155-160
English
7.6

ROPS MAINTENANCE

ROPS Inspection
Inspect the ROPS after the first 20 hours of operation.
• Check the torque of the ROPS mounting bolts. Tighten
the bolts to the correct torques (M12, 95N.m) if
necessary.
• Inspect the operator's seat and the mounting parts for the
seat belt. Tighten the bolts to the correct torque as shown
below, if necessary, and replace parts that show wear or
damage.
Oil brand
• Inspect the seat latch to make sure it is secured and
functioning properly. Adjust or repair, as necessary.
GL-5
Possible damage to the ROPS
85W-140
If the unit has rolled over or the ROPS has been in some other
type of accident (such as hitting an overhead object during
transport), the ROPS must be replaced to retain the best
protection. Following an accident, check the ROPS, the
operator's seat, the seat belt, seat belt mountings and seat
latch for possible damage. Before operating the machine,
replace all damaged parts.
The ROPS structure's protective capability may be
impaired by structural damage, overturn or alteration. Do
not remove or alter any of the ROPS parts. Do not attempt
to weld or straighten ROPS. Failure to adhere to these
instructions could result in severe injury or death.
7.7

BATTERY PACK MAINTENANCE

Your Cramer mower is powered by a battery pack which,
when maintained properly, will provide years of useful life.
For proper care, adhere to the following instructions:
• Always charge batteries after each use.
• Whenever a battery pack is fully discharged and turned
off, it is best to recharge the battery as soon as possible.
Over-discharge of the battery pack means the battery life
will be shortened and the battery may become
permanently damaged. There is no need to fully charge; it
will be beneficial even if you only charge the battery pack
for 5-10 minutes. It is best to recharge it within 24 hours.
• Check that battery cables are securely tightened to
batteries each time you service the battery.
• Keep grass, dirt and debris from collecting near battery
terminals and in battery area.
• Charge batteries indoors in a well-ventilated and dry
location away from sparks or flames. Never expose
charger to rain, vapor or liquid.
• Charge only lithium batteries provided by Cramer.
• Do not touch uninsulated portion of charger (terminal
pins) or of output connector.
• Do not use with defective cords and wires. Replace
defective cords and wires immediately.
14
