4.2.3 STOP THE MACHINE
Never make sudden stops or reverse direction, especially
when maneuvering on a slope. The steering is designed for
sensitive response. Rapid movement of the steering control
levers in either direction could result in a reaction of the
machine that can cause serious injury.
1. Return drive control levers to the Neutral position. Push
drive control levers outward into park brake position.
2. Push down on deck blades ON/OFF to turn off the blades.
3. Press the push button switch.
It is recommended to remove the magnetic bar from the
machine to prevent accident start of the machine.
4.3

SLOPE OPERATION

• Use extreme caution when operating on slopes.
• Do not remove or modify any wheels.
• Watch for holes, ruts, bumps, rocks or other hidden
objects. Uneven terrain could overturn the machine. Tall
grass can hide obstacles.
• Remove obstacles such as rocks, tree limbs, garbage etc.
• Keep all movement on slopes slow and gradual. Do not
make sudden changes in speed or direction.
• Avoid starting and stopping on a slope. If tires lose
traction, disengage the blades and proceed slowly straight
down the slope.
• Mow a safe distance (minimum of 3 meters) away from
drop-offs, retaining walls, drainage ditches,
embankments, water, and other types of hazards to avoid
a wheel dropping over the edge or the ground breaking
away. This will reduce the risk of the machine suddenly
rolling over, which could cause either serious injury or
death.
• Use a walk-behind, push mower or hand-held trimmer on
slopes and near drop-offs, retaining walls, drainage
ditches, embankments and water.
• Do not mow on wet grass. Reduced traction could cause
sliding and loss of steering control.
• Do not tow on slopes. The weight of the towed equipment
may cause loss of traction and control.
• If the mower's tires lose traction when operating on
slopes, disengage the deck drive, place the steering
control levers in the park brake position, press the push
button switch, remove the magnetic bar and get help.
• Never make sudden starts, stops, turns, or reverse
direction, especially when maneuvering on slopes. The
steering is designed for sensitive response. Rapid
movement of the steering control levers in either direction
could result in a reaction of the machine that can cause
serious injury.
DANGER
CAUTION
English
• Never stop suddenly while backing down slopes. This
action may result in a reaction of the machine that can
cause serious physical injury.
• The Cramer mower is capable of operating horizontally
(traverse) on moderate slopes. When operating on slopes
up to 20 degrees, be aware of any conditions that may
cause the mower drive tires to lose traction, resulting in a
possible loss of control of the machine. An operator
should not operate on a slope until he is thoroughly
familiar with the equipment.
Do not operate on slopes greater than 20 degrees.
Refer to Slope Guide, when determining the degree of
slope to be mowed. It is strongly recommended that the
operator drive the machine off of the slope, using extreme
caution, if any sign of loss of traction is detected. Wait
until the condition that caused the problem is resolved
before attempting to operate on the slope again. Terrain
conditions can affect traction, resulting in possible loss of
control of the machine. Some of the conditions to be
aware of are:
1. Wet terrain
2. Depressions in the ground (e.g., holes, ruts, washouts)
3. Mounds of dirt
4. Certain types of soil (e.g., sand, loose dirt, gravel,
clay)
5. Grass type, density, and height
6. Extremely dry conditions
7. Tire pressure
The attachments mounted to the mower will also affect
the way it handles on a slope. Be aware that each
attachment's characteristics vary.
These are just a few examples of situations where caution
must be used when operating on a slope. There are many
other possibilities too numerous to mention. Remember to
always exercise extreme caution while operating on any
slope.
• The ROPS may minimize risk of injury or death from
rollover. Seat belt must be fastened while operating a
mower equipped with ROPS in the raised and secured
position. Both retaining pins and hair pins must be
installed. Failure to use seat belt with ROPS will result in
serious injury in the event of a rollover.
4.4

APP OPERATION TIPS

1. MOBILE APPLICATION
See separate figure sheet 13
Find the serial number, pairing code and QR code in the
vehicle matching label.
2. REGISTRATION AND LOGIN
See separate figure sheet 14
Step 1. Fill in the registration information (with * is
required), and then click the "Create" button.
