Electrical System; Electrical System Safety; Electrical System Information; Battery And Charger - Cramer 82ZT132 Bedienungsanleitung

Model No. Battery capacity
82ZT132 3% - 6%
• Allow motors 30 minutes to cool down. If drive motor exceeds programmed temperature, the motor speed will decrease. If
temperature continues to increase, drive will shut down at a higher programmed temperature.
6

ELECTRICAL SYSTEM

6.1

ELECTRICAL SYSTEM SAFETY

• Remove the magnetic bar, disconnect battery cables by
pulling inward on RED battery quick disconnect handle
in battery box compartment and read owner's manual
before adjusting or repairing unit.
• Always remove the magnetic bar and disconnect battery
cables by pulling inward on RED battery quick
disconnect handle in battery box compartment before
working on this unit.
• Always disconnect battery cables by pulling inward on
RED battery quick disconnect handle in battery box
compartment when transporting unit.
• Keep unit free of grass clippings, leaves and other debris.
DO NOT spray water to clean unit. Use only compressed
air. Wear adequate eye and hearing protection when
cleaning the unit.
• Always wear safety glasses and protective gear near
battery. Use insulated tools.
• Clean battery compartment, drive motor compartment,
mower deck, seat, etc., of all dirt and debris. Do not use
solvents, hard cleaners or abrasives.
• When the power switch activated, mower blade can
engage when deck blade ON/OFF switch is engaged,
even if drive motor is not turning. Keep area clear of
bystanders when engaging deck blade ON/OFF switch.
• All maintenance and storage areas should be properly
ventilated in accordance with applicable fire codes and
ordinances to avoid fire hazards. Proper ventilation is
required to remove hydrogen gas from the area during
battery charging.
• Never allow flames, sparks or smoking near batteries.
• Keep batteries out of reach of children.
• Always keep protective shields, covers and guards in
place and securely fastened. If they become damaged,
repair or replace immediately. Never modify or remove
safety devices.
English
Action
The maximum drive speed
will be 9 km/h and the unit
will operate in lower blade
speed mode.
6.2 ELECTRICAL SYSTEM
INFORMATION
The Cramer mower is powered by an 82-volt electrical
system. It consists of the following components:
1. Blade controller (3) (Depending on model)
2. Blade Motor (3) (Depending on model)
3. Drive controller (2)
4. Accelerator - right (1)
5. Accelerator - left (1)
6. Digital display (1)
7. Motor drive assembly (2)
8. Battery pack (1)
6.3

BATTERY AND CHARGER

Maintenance for the various electrical components found on
the Cramer Mower should only be performed by a Cramer
Mower trained technician.
When battery voltage becomes low, the mower blades will
stop, although the drive motors will continue to run,
enabling driver to continue to drive unit. When the batteries
discharge to this point, they require recharging. The unit
should immediately be returned to the battery charging area
and the unit connected to the battery charger.
Do not attempt to cross roads or railways with low battery
levels.
6.3.1 BATTERY CHARGING PORT
See figure 10
The battery charging port is located on the right (with
operator seated) housing of the machine. Open the port cover
to charge. Both quick charging port and standard charging
port are available.
11
Battery capacity Action
The working blade will
stop automatically. The unit
should immediately be re-
<3% turned to the battery charg-
ing area and the unit con-
nected to the battery charg-
er.
WARNING
WARNING
WARNING
EN
