# Name Function
18 High/Low Allows operators to select a comfortable
for driving driving speed. Pressing it to "High
speed Speed"" position means that the maxi-
mum drive speed will be 16 KM/H.
Pressing it to "Low Speed" position
means that the maximum drive speed
will be 9 KM/H. Press it to "Low Speed"
position for inexperienced operators or
when trimming around objects, buildings
and other obstacles.
Get comfortable with mower before us-
ing "High Speed" setting. The maxi-
mum speed may be adjusted at any
time, whether the mower is in motion
or not.
19 ON/OFF for This switch engages the blade motors.
blade (PTO) Pull the switch up to engage and push
switch down to disengage the motors.
20 Power The machine can be used togheter with
ON/OFF for other attachments and accessories.
accessory
(ETO)
21 High/Low The user can choose between two cutting
for blade modes. High blade speed mode and low
speed blade speed mode. Selection is depend-
ent on grass enviroment.
Mowing time will be increased when
mowing in low blade mode.
IMPORTANT
Never engage blade motors when the deck is under load.
Motors or deck could be damaged.
3.3

STEERING CONTROL LEVERS

The two levers control the mower's speed, direction,
stopping, neutral lock, and parking brake. Levers are used to
steer, accelerate, decelerate, stop, and change direction. When
the control levers are in the park brake position, the mower
will not move.
3.4 SAFETY START INTERLOCK
SYSTEM
The machine is equipped with a safety start interlock system
consisting of the parking brake switches, seat switch, and
PTO switch.
English
NOTE
NOTE
5
The mower's safety start interlock system is also designed to
protect the operator and others from accidental injury due to
unintentional traction drive system starting.
Check mower safety start interlock system daily, prior to
operation. This system is an important mower safety feature.
It should be repaired immediately if it malfunctions. The
machine incorporates a separate seat switch which will stop
the drive system and blade motors when the operator is
unseated for any reason while the mower is operating. This is
a safety feature designed to prevent runaway or accidental
entanglement.
WARNING
The safety interlock system must not be disconnected or
bypassed. Doing so could cause the machine to operate
unexpectedly, resulting in personal injury.
To inspect the system:
1. The operator must be on the seat when testing the seat
switch.
2. Press the push button switch with magnetic bar inserted.
3. Pull the steering control levers to the neutral position.
4. Pull the PTO switch ON to engage the motor.
5. Slowly raise off of the seat. The deck blade system should
stop.
6. If the deck blade system fails to stop when the operator is
off of the seat and if the cause cannot be determined,
contact your Cramer dealer immediately.
3.5 ROPS (ROLL OVER PROTECTIVE
STRUCTURE)
A ROPS may minimize the Risk of injury or death from
rollover. The two-post ROPS can be pivoted down by
removing the clevis pins after pulling out on the R-pins so
that the machine can operate under low-hanging tree limbs or
other obstructions. Do not wear the seat belt when the ROPS
is in the lowered position. Use the ROPS in the "folded"
position only when it is absolutely necessary.
WARNING
Do not operate the mower with the ROPS folded (lowered
position) -- a standard operating mode. A folded ROPS does
not provide rollover protection.
WARNING
Always wear your seat belt unless the ROPS is folded
down. In this case, the seat belt should never be worn.
