7.

Technical Specifications

TG 100R diversity receiver
Operating principle . . . . . . . . . . . . . . . . . . Diversity Receiver
Frequency range. . . . . . . . . . . . . . . . . . . . Band 1 = 174 - 184 MHz,
Frequency response . . . . . . . . . . . . . . . . . 100 Hz - 16 kHz
Dynamic range . . . . . . . . . . . . . . . . . . . . . 112 dB
Output level . . . . . . . . . . . . . . . . . . . . . . . max. 0 dBV (XLR and jack output)
Mains connection . . . . . . . . . . . . . . . . . . . 100 V - 240 V AC; 12V DC power supply unit
Power consumption . . . . . . . . . . . . . . . . . 150mA
Ambient temperature . . . . . . . . . . . . . . . . 0 to +55 °C
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . 250 g
Dimensions . . . . . . . . . . . . . . . . . . . . . . . 143 x 100 x 41 mm
Antenna connection . . . . . . . . . . . . . . . . . 2 x telescopic, permanently attached antennae
TG 100H handheld transmitter
Frequency range. . . . . . . . . . . . . . . . . . . . Band 1 = 174 - 184 MHz,
Frequency response . . . . . . . . . . . . . . . . . 100 Hz - 16 kHz
Dynamic range . . . . . . . . . . . . . . . . . . . . . 112 dB
RF power . . . . . . . . . . . . . . . . . . . . . . . . . < 10 dBm
Transmission range . . . . . . . . . . . . . . . . . . up to 80 metres under optimal conditions
Operating time . . . . . . . . . . . . . . . . . . . . . approx. 10 hrs.
Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . 200 g without batteries
Dimensions . . . . . . . . . . . . . . . . . . . . . . . Length 254 mm /
8.

Service

In the unlikely event of equipment failure, the product should be returned to your beyerdynamic
dealer. Unauthorised attempts at repair may invalidate the warranty.
9.

Licensing

In most countries around the world, wireless systems must be approved for use by the authorities and
it may be necessary to obtain a licence to use it legally. Your local beyerdynamic dealer will be able
to give you details on wireless system regulations for your area.
The components of the TG 100 system are approved according to the EU directive R&TTE 99/5/EEC:
"TG 100B Beltpack Transmitter"
"TG 100H Handheld Transmitter"
under the CE 0681 ! identification
Band 2 = 194 - 204 MHz
Band 3 = 213 - 223 MHz
Band 2 = 194 - 204 MHz
Band 3 = 213 - 223 MHz
Shaft ø 36 mm
Microphone grille ø 50 mm
TG 100 – Licensing
