TG 100 – Handheld Transmitter
3.2

How to Operate the Handheld Transmitter

How to insert or change the batteries
• Unscrew the cover of the battery compartment
• Slide the cover of the battery compartment
• Insert two alkaline batteries, AA 1.5 V or rechargeable NiMH batteries according to the symbols in
the battery compartment
• Slide the cover of the battery compartment
How to turn the transmitter on or off
• Turn on the handheld transmitter by holding the on-off button
for operation when the on-off button
permanently illuminate green.
• If the on-off button
The left LED on the receiver will permanently illuminate red. In this case, you should replace
the batteries as soon as possible by new ones or recharge the rechargeable batteries.
How to select or change a channel
• Make sure that transmitter and receiver operate on the same frequency. Switch off the transmitter.
Unscrew the cover of the battery compartment
• Select the channel of the transmitter with the channel selector switch
ment according to the channel of the receiver (0 - 7) by using a small screwdriver.
• In order to turn off the handheld transmitter hold the on-off button
the green LED in the on-off button
.
will illuminate green. The left LED
of the transmitter will permanently illuminate red, the batteries are empty.
will go out.
anti-clockwise.
downwards.
upwards again and tighten it clockwise.
pressed. The transmitter is ready
anti-clockwise and slide it downwards.
pressed for a few seconds, until
27
on the receiver will
in the battery compart-
