TG 100 – Receiver
2.2

How to Operate the Receiver

Where to place the receiver
• Place the receiver in the same room where the transmission takes place.
• Place the receiver as close as possible to the transmitter. For optimal reception, a free line of sight
is advisable between transmitter and receiver.
• Do not place the receiver near digitally controlled devices.
How to connect the receiver to the mains
• Verify that the voltage rating of the power supply matches that of the mains outlet that you are
using.
Warning: If you connect the receiver to the wrong voltage, you may cause damage.
• Connect the supplied power supply to the DC connection
has no separate on-off switch and will immediately be ready for operation indicated by the right
LED illuminating green. Do not use any other power supply, only the one supplied or
recommended by beyerdynamic.
• To disconnect the receiver from the mains, pull the power supply out of the mains socket.
How to extend the antennae
• The antennae are permanently attached on the front of the receiver. Extend the antennae completely
and set them at an angle (approx. 60°) in the shape of a "V". A weighting circuit ensures that an
antenna is selected that supplies the better signal.
How to connect the receiver to a microphone input
• The receiver is provided with balanced audio outputs.
• Connect the balanced XLR
console or amplifier.
• Adjust the level of the audio output to the input level of the amplifier or mixing console by using
the volume control
Important:
If the level is set too high, the audio signal will be distorted. If the level is set too low, it will result
in an audio signal with high background noise.
We recommend the middle position for first tries.
How to select or change a channel
• With the channel selector switch
Check the receiver, if the selected channel is free from interference (left LED
green when the transmitter is turned off).
Important: The channel of the receiver must match the channel of the appropriate transmitter.
or jack output
.
you can select one of 8 channels (0 - 7).
and to a mains socket. The receiver
to the balanced microphone input of a mixing
25
must not flash
