Except for the start screen, for all other RVT screens, each screen has three parts: title bar at the top, status bar at
the bottom, and the setting area in the middle of the screen.
3.2.2.
Title bar
At the left end of the title bar, the blue Mode button is used to switch between the three RVT operating modes: Auto-
matic mode, Manual mode and Set mode. The following screen as shown in
is clicked. When one mode is set to the RVT, for instance, the Set mode is set, the one-letter uppercase initial will be
indicated at bottom right of the screen: the
is in Set mode.
In the middle of the title bar, the text, like the "Measurements" in the
screen.
STATUS
Approved
close window
Validation
next page
Figure 14: RVT screen composition
at the right end of the status bar means the current mode of the RVT
Figure 15: RVT modes switching
SECURITY LEVEL
Public
PO WE R FACTO R CON TR O LL ER RV T
Title bar
Setting area
Status bar
Figure 15
Figure
14, displays current menu displaying in the
DOCUMENT ID
9AKK107045A9645
appears when the Mode button
REV.
LANG.
PAGE
D
en
23/542
