4.2.
VG BASIC
7
5
7
4
6
3
2
1
1 Infinite fine adjustment X-
axis
2 Z-axis and X-axis quick ad-
justment
3 Infinite fine adjustment Z-
axis
4 Tower
5 Rear of tool mounting with
main switch
6 Optical unit with CMOS digital camera
4.3.
PANEL PC
3
Fig. 1: Rear of panel PC
1 On/Off switch
2 Screen locking for swivel function
4.4.
CONNECTIONS
4.4.1.
Rear of base body
1
2
Fig. 2: Connections at the rear of the base body
8
9
10
11
7 Transillumination
8 Anti-rotation arm
9 Tool mounting (SK50 taper
needle roller bearing with
interchangeable SK50
needle roller bearing
sleeve)
10 Panel PC with 10 inch
touch screen
11 Adjustable feet with screw
threads
1
2
3 USB port
3
1 Connection for com-
pressed air
2 Connection for low-voltage plug for power supply
4.4.2.
Internal service unit
3
Fig. 3: Internal service unit
1 Rotary knob with locking
4.5.
NAMEPLATE
4
3
2
1
www.hoffmann-group.com
It may not be removed or covered.
If it is damaged or becomes very dirty, fit a new nameplate. Con-
tact Hoffmann Group customer service.
Located on the left side of the pre-setting device housing.
1
Power consumption
2
Serial number
3
Manufacturer's address
4
Brand
4.6.
START SCREEN OF THE MEASUREMENT SOFTWARE
8
HSK50
HSK63
SK40
7
SK50
6
5
Fig. 4: Start screen of the measurement software
1
Adapter currently selected
2
Adapter sorting number (ID) 4 Creating a new adapter
Tab. 1: Adapter display
5
Settings
www.hoffmann-group.com
3 Main switch
1
2, 3 Connections for com-
pressed air
355010 VGBasic
Hoffmann Supply Chain GmbH
Franz-Hoffmann-Str. 3
90431 Nuremberg, Germany
Item Number:
355010 VGBasic
Serial Number:
00001
Manufactured:
06/2020
Voltage:
1/N/PE-AC 100-240 V / 50-60 Hz
Pneumatic System:
4 - 6 bar
5
CE mark
6
Article number
7
Build year
8
Pneumatic system working
pressure
1
2
SK 40
ID: 1000
X
44,986
mm
R
Radius
Notes
New adapter
Calibrate the adapter
4
3 Edit the adapter selected
7 Adapter overview and cre-
ation
en
2
5
6
7
8
3
mm
Z
-2,919
19
