App Control - Scheppach XXL900 Bedienungs- Und Sicherheitshinweise Originalbetriebsanleitung

• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new start time is stored. The word "IdLE"
appears on the display.
9.2.4 Changing the mowing time/day (Fig. 24)
The factory-set mowing time per day of 6 hours can
be changed at any time.
• Press and hold the "OK" button for at least 3 sec-
onds.
• The display shows the set mowing time, e.g. 06 H,
with the first digit flashing.
• Use the "START" and "HOME" buttons to select the
desired digit and confirm with the "OK" button.
• After confirming the second digit with the "OK" but-
ton, the new mowing time or the new day is stored.
The word "IdLE" appears on the display.
9.3 Mowing edges
The default setting is for the robot mower (1) to mow
the edges every Tuesday and Friday.
This means that the robot mower (1) travels once
along the boundary wire (11) the first time it mows
for the day.
m ATTENTION
In this mode, the blade disc (6) is active.
The times for edge mowing can only be set via the
app.

9.4 App control

The RoboCut XXL 900 robot mower can be operated
via app. The app is available in the respective app
stores for Android and iOS.
m ATTENTION
The use of the app falls under the term "using"
as defined in this operating manual. Therefore,
also observe the safety regulations that apply to
this.
9.4.1 Registration
In order to use the app, registration via email is nec-
essary. Alternatively, you can also register and log in
via Facebook, with your Apple ID or with google.
Have the serial number of your robot mower ready
for registration. You will find this on the type plate of
the unit.
9.4.2 Communication / data transmission
The app communicates with the robot mower either
via Bluetooth or WiFi.
m NOTE
Depending on your contract with your mobile phone
provider or internet provider, the data transfer from
the app to the internet may incur costs that you will
have to bear yourself.
9.4.3 Functions of the app
• Viewing and editing the mowing plan
• Adjusting the mowing zones
• Starting mowing
• Send the device to the charging station
• Settings
• Updates / read out (log data)
9.4.3.1 Viewing and editing the mowing plan
With this function you can set when the robot mower
should start mowing and how long it should mow for
each individual day.
There is one start time per day (later max. two start
times) available.
In this function you can also set the days on which
the lawn edges are to be mown.
m ATTENTION
Changing the mowing schedule, starting a mow-
ing operation, switching the automatic on and
off, sending the robot mower home and changing
the date and time may result in activities that are
not expected by other people. Affected persons
must therefore always be informed in advance
about possible activities of the robot mower.
9.4.3.2 Adjusting the mowing zones
In this function you can manually set up four differ-
ent mowing zones in %. By default, the function is
set to "AutoMultizone". Here, the mower starts after
each charging process at an arbitrary place along
the boundary wire.
www.scheppach.com
Art-Nr.: 3913001xxx
. n . 36 Wh
20V : 2800 min -1
0
Ø 18 cm . 8 kg . IPX5
manufactured: 12/2020 S.Nr.: 0169-01001
Woodster GmbH - Günzburger Straße 69 - 89335 Ichenhausen - Germany
GB | 31
