m ATTENTION
The robot mower is not switched off, it has only been
stopped. Always use the "POWER ON/OFF" button to
switch the robot mower off.
Switching the robot mower on:
• The robot mower can then be restarted as de-
scribed below.
m NOTE
Before the robot mower (1) starts mowing, an acoustic
signal (four beeps) is heard, then the blade disc (6)
starts rotating.
• Press the button ("POWER ON/OFF" button) until
the robot mower (1) switches on.
• For the first use, enter the default PIN code "0000"
by pressing "OK" four times when the number "0"
flashes. (The PIN code can be changed as de-
scribed in point 9.2.1).
• After confirming the fourth digit with the "OK but-
ton", the robot mower is ready for use. The word
"IdLE" appears on the display.
m NOTE
The robot mower (1) switches off automatically after
30 seconds if no input is made.
m ATTENTION
If the PIN code is entered incorrectly 10 times, "LOCK"
appears on the display. The device is now locked for
10 minutes before you can enter the PIN code again.
• Press the "START" button and then the "OK" button
to start mowing.
• If you press the "HOME" button and then the "OK"
button, the robot mower (1) returns to the charging
station (10) with the mowing function switched off.
The robot mower (1) operates continuously until the
battery charge is too low. The robot mower automat-
ically returns to the charging station (10). The cutter
disc is deactivated in this state.
m NOTE
After the rechargeable battery is fully charged, the ro-
bot mower starts again. Alternatively, the robot mow-
er remains in the charging station (10) in accordance
with the set mowing schedule.
(By default, the robot mows from Monday to Friday
from 09:00 - 15:00 hrs)
9.2. Settings
m NOTE
To make adjustments to the product, the robot mower
(1) must be switched on. Switch the robot mower (1)
on by pressing and holding the
ON/OFF" button) until "PIN" appears on the display.
30 | GB
button ("POWER
www.scheppach.com
9.2.1 Changing the PIN code (Fig. 21)
• Press and hold the "START" and "HOME" buttons
simultaneously for at least 3 seconds.
• The symbol and "PInI" flash.
• Now enter the old PIN code as follows (factory set-
ting "0000").
• The first digit illuminates ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit illuminates (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After you have entered the "old" PIN code and con-
firmed the fourth digit with the "OK" button, "PIn2"
appears, now you can enter the new PIN code.
• The first digit flashes ("0---").
• Use the "START" and "HOME" buttons to select the
desired digit.
• Confirm the digit with the "OK" button.
• The next digit flashes (e.g. "10--).
• Proceed as described in paragraph 2-4 above.
• After confirming the fourth digit with the "OK" but-
ton, the new PIN code is stored. The word "IdLE"
appears on the display.
9.2.2 Setting/changing the date/time (Fig. 22)
m NOTE
Date and time are necessary settings so that the robot
mower (1) can mow in accordance with the set mow-
ing schedule.
• The date/time setting is done in the order year - date
- time.
• Press and hold the "START" button for at least 5
seconds.
• The symbol and "PInI" flash.
ber (e.g. 2020) flashes on the display.
• Use the "START", "HOME" and "OK" buttons to set
the year, similarly to the PIN setting.
• Then the next number illuminates (month.day e.g.
08.25 for 25 August).
• Use the "START", "HOME" and "OK" buttons to set
the correct month and day.
• The time is displayed last (e.g. 13:25).
• Set the current time as described above.
• After confirming the fourth digit with the "OK" but-
ton, the date and time are stored. The word "IdLE"
appears on the display.
9.2.3 Changing the start time (Fig. 23)
The factory-set start time of 09:00 can be changed at
any time.
• Press and hold the "START" and "OK" buttons si-
multaneously for at least 3 seconds.
• The display shows the set start time, e.g. 13:25, with
the first digit flashing.
- symbol and a num-
