1. DESCRIPTION OF THE HOIST
The Tralift™ Cleantech hoist is designed for
lifting and lowering a load suspended on a
EN
chain (load chain) by manually actuating a
second chain (hand chain); it is also used to
maintain a load suspended.
The Tralift™ Cleantech hoist is secured to
a fixed anchor point or to a moving trolley.
Information about suspension trolleys can be
obtained from TRACTEL
Manufactured from high­quality materials,
the Tralift™ Cleantech hoist is a robust
tool. The hoist has a compact design, is
light­weight, portable and easy to install.
The Tralift™ Cleantech chain hoist range is
specially designed for applications in the food,
pharmaceutical, cosmetic and cleanroom
sectors but also in aggressive environments
with salt water or dust due to their excellent
corrosion resistance.
The Tralift™ Cleantech chain hoist consists
mainly of stainless steel components and is
equipped with a stainless steel lifting chain
and operating chain. The grease used in the
gearbox is a food grade grease.

2. TECHNICAL SPECIFICATIONS

1: load chain
2: lifting hook
3: pulley block
on request.
®
W.L.L.* :0.5t­1t
4: low limit stop
5: suspension hook
6: safety catch
The Tralift™ Cleantech hoist is supplied
equipped with a load chain (item 1, fig. 1) and
a hand chain (item 7, fig. 1) compatible for a
standard lifting height of 3 m.
The load chain is formed by one or several
strands (see §2 technical specifications),
equipped with a lifting hook (item 2, fig. 1)
on its load­end side ; on the other end (slack
strand side), the load chain is secured to a
low limit stop (item 4, fig. 1) itself secured to
the hoist.
The Tralift™ Cleantech hoist complies with
the requirements of the European directive
2006/42/CE and The Supply of Machinery
(Safety) Regulations 2008 (SI 2008/1597) of
the United Kingdom and is designed to ensure
a minimum mechanical strength of 4 x WLL*.
The Tralift™ Cleantech hoist is designed and
built to withstand dynamic testing at 1.1 x
WLL* and static testing at 1.5 x WLL*.
Description of a standard delivery: the hoist
is supplied in a cardboard package equipped
with its hand and load chains, and comes
with its user manual, CE compliance certificate
and UKCA certificate.
W.L.L.* :2t
fig. 1
7: hand chain
