6 System settings menu

11 Quick unit selection (if using several units)

5.2.2 Main menu value call-up

Here current unit values such as temperature and
humidity measurement values, unit statuses or
fault messages can be called up.

5.2.3 Operating mode selection

Set the basic mode of operation of the ventilation
unit with the operating mode.
Operating mode Mode of opera-
Auto time
Auto sensor
Manual
Eco mode supply
air
Eco mode ex-
haust air
Off
Choose between automatic operating modes
(Auto time, Auto sensor) and manual operating
modes (Manual, Eco mode supply air, Eco mode
exhaust air and Off).
5.2.4 Ventilation level short code
Activates the ventilation level. The setting is avail-
able in a manual operating mode.
Ventilation level Mode of operation
Humidity protec-
tion ventilation
24
tion
Activates the regu-
lar time pro-
gramme/holiday

time programme.

Automatic opera-
tion with sensor
control.
Manual mode
Energy-saving
summer operation
with supply air fan
Energy-saving
summer operation
with exhaust air
fan
Standby mode
(fans off)
Interval operation,
approx. 43 % of re-
duced ventilation
(according to DIN
1946-6).
Ventilation level 1 Continuous opera-
Ventilation level 2 Nominal ventilation
Intermittent ventil-
ation
Ventilation level 3 Intensive ventilation
6 System settings menu
Basic control unit settings, such as
key lock or luminosity, can be con-
figured in the System settings menu.
You can also switch to the installer
level. Within this level, the system
configuration for the multiple-unit
connection (max. 10 unit) to the
RLS T1 SYS should be set.
6.1 Operating structure for system
settings

Display

Time programme

System

Installer

Software version

Error memory

tion with reduced
ventilation RV
NV
Time-limited intens-
ive ventilation IV
(with timer).
IV
