Battery; New Battery - First Charging; Low Battery Indication; Battery Discharged Indication - mectron starlight pro Gebrauchs- Und Wartungsanleitung

Power LED Battery LED
ON OFF
Table 3 – Description of light signals on the charging unit.
CAUTION: Do not tamper with the charging unit electrical contacts.
the charging unit recognizes the battery state. If after some exposure cycles the battery is not
enough discharged, when the handpiece is placed on the charging unit, the green battery LED
doesn't switch on. this is an expected behaviour.
5

BATTERY

starlight pro is powered by a rechargeable lithium-ion battery already contained inside the
handpiece, with no memory effect.
starlight pro is equipped with two microprocessors that check the battery continuously and
maintain the optimum battery charging parameters. The handpiece may therefore be placed
back into the charging unit at the end of each treatment and left there, regardless of the charge
of the battery.
5.1 New Battery - First Charging
NOTE: The battery of the starlight pro is provided partially charged.
To charge completely the battery:
1. Place the handpiece into its housing in the charging unit (Figure 5 at page 10 - Ref. B).
The green battery LED will light up (Table 1 at page 11 - Ref. B).
2. the charging phase has been completed when the battery LED switch off.
5.2 Low Battery Indication
When the charge of the battery becomes low, after frequent use of starlight pro, the
microprocessor will allow 6 more exposures to be carried out (FASt or SLOW rISE) without any
need to recharge the battery.
A battery low state is signalled at the end of each of these 6 cycles by means of 2 beeps.
Once the 6 cycles have been completed, the handpiece enters a battery discharged state (see
Chapter 5.3 on page 13
Place the starlight pro handpiece back into the charging unit.
5.3 Battery Discharged Indication
the battery of starlight pro is discharged if no light is emitted when pressing the on/off button
and at the same time an acoustic signal is produced (2 beeps). Recharge the battery:
Test LED
Green ON
).
Position of the
handpiece in
Function
the charging
unit
Light emission
suitable for
Not inserted
an effective
treatment.
BATTERY
13
