Connection diagram
SS-1296:
VDD 315/4 T120
VDD 355/4 T120
VDD 400/4 T120
VDD 400/6 T120
VDD 450/4 T120
VDD 450/6 T120
VDD 500/6 T120
VDD 560/6 T120
Connection diagram
SS-1130:
VDD 500/4 T120
VDD 560/4 T120
VDD 630/6 T120
VDD 710/6 T120
Roof fans – VDD T120
1. Connect unit in accordance with the connection diagrams, see following section 5.2 "Connection diagrams".
2. The following must be checked:
• Network configuration, voltage and frequency must be consistent with the rating plate information.
• In principle, the motors are wired in the clockwise field of rotation for clockwise rotation (see directional arrow).
• Protective conductors, including additional equipotential bonding, must be properly installed!
• Check the waterproofing of the connection cable and tight clamping of the strands.
• The insertion of the supply line must be carried out by specialists! The connection line in the terminal box/ isolator
switch (IP 65) must compensate for the potential fan vibrations.
5.2

Connection diagrams

3~ Motor
M
mit TB (TK)
RS 3+1+2
3~ Motor
mit TB/TP (TK/KL)
Farbcode nach IEC 757
U1
V1
W1
U2
V2
W2
TB/TP WH-ws-weiß-white
PE
Schalter
7
85499 058 SS-1296 23.02.18
BN-br-braun-brown
BU-bl-blau-blue
BK-sw-schwarz-black
RD-rt- rot-red
GY-gr-grau-grey
OG-or-orange-orange
YE-GN-ge-gn-gelb-grün
-yellow-green
85419 001 SS-1130 14.09.16
Fig. 3
Fig. 4
