TECKERBELEGUNG

MAC 2000 Profile PCB

24V AC RED 24V AC RED
24V AC BLACK 24V AC BLACK
12V AC ORA. 12V AC ORA.
12V AC YEL.
HEAD TEMP. SENSOR HEAD TEMP. SENSOR
20 (GOBO SENSOR) 20 (GOBO SENSOR)
19 (EFFECT, ROT. 19 (EFFECT, ROT.
EFFECT SENSOR)
21 (P/T SWITCH) 21 (P/T SWITCH)
6 (COLOR) 6 (COLOR)
5 (GOBO 1) 5 (GOBO 1)
8 (GOBO 2) 8 (GOBO 2)
1 (EFFECT WHEEL) 1 (EFFECT WHEEL)
2 (ROT.EFFECT) 2 (ROT.EFFECT)
7 (IRIS) 7 (IRIS)
23 (OPTO 2) 23 (OPTO 2)
40
F902
FUSE
6.3 AT
PL905
PL904
PL901
PL903
+30V
+12V
+5V
TRANSMISION DISA.
TRANSMISION ENA.
LINK
+5V ISO
18 (CMY SWITCH) 18 (CMY SWITCH)
PL701
PL604
PL605
PL601
PL602
PL603
PL503
PL502
PL501
PL302 PL301 22 (OPTO 1) 22 (OPTO 1)
LD401
25
PAN
25
P/N 33120024-B
MAC 2000 Profile
H
AUPTPLATINE
F901
FUSE
4.0 AT
PL214 PL212
PL309
PL308
PL307
D
PL306
(DOOR
CPU PL303
SWITCH)
PL304
PL305
PL104
PL105
LOCK
PL106
BOOT
PL107
UPLOAD ENA.
UPLOAD DISA.
PL1109
PL1182
PL1101
PL1009
PL1002
PL1001
PL902
PL704
PL804
PL805
LD402
26
TILT
26
BROWN
BLACK
ELEC. BALLAST ELEC. BALLAST
FAN BASE FAN BASE
FAN BASE FAN BASE
F2 (FAN HEAD LARGE) F2 (FAN HEAD LARGE)
(FAN HEAD LARGE) (FAN HEAD LARGE)
11
(FAN HEAD SMALL) (FAN HEAD SMALL)
F1 (FAN HEAD SMALL) F1 (FAN HEAD SMALL)
24 (LIGHT SENSOR) 24 (LIGHT SENSOR)
DISPLAY
3 (ZOOM) 3 (ZOOM)
9 (FOCUS) 9 (FOCUS)
15 (CTC) 15 (CTC)
13 (YELLOW) 13 (YELLOW)
14 (MAGENTA) 14 (MAGENTA)
16 (CYAN) 16 (CYAN)
GND
12 (DIMMER) 12 (DIMMER)
4 (ROT. GOBO 1) 4 (ROT. GOBO 1)
10 (ROT. GOBO 2) 10 (ROT. GOBO 2)
