15. Technical data

15.1 Technical data

Model code

Serial number

Year of manufacture

Max pressure PS
Project number
Fluid type
Internal volume
Weight
Sound pressure level
Current
Voltage
15.2 Identification code
Series Fan
diameter number
CGC 25
25 = Ø250
31 = Ø315
35 = Ø350
15.3 Documents supplied with the current model or available at: https://www.modinecoolers.com/documents/
15.3.1 Technical Manual - Instructions for Use
15.3.2 Declaration of Incorporation
15.3.3 Operating Manual - Fans (as long as required)
15.3.4 Circuit diagram (if applicable)
15.3.5 User's manuals for accessories (if any)
48
www.modine.com
Label on the unit
Label on the unit
Label on the unit
Label on the unit
Documents relating to offer / order
Documents relating to offer / order
Label on the unit
Label on the unit
Documents relating to offer / order
Label on the unit and Technical manual Chapt. 9
Label on the unit and Technical manual Chapt. 9
Fan Rows Fin spacing
1 E 4
1 A = 6 4 = 4mm
2 E = 4 6 = 6mm
3 F = 5 8 = 8mm
4 G = 3
5
Reduced module Electric defrost
R ED
[R] = optional reduced
[ED] = optional electric
module
defrost
[Ø250 only]
Features
.1079
[.xxxx] = optional
features
