7. Construction and dimensional features

Ø250 fan diameter unit
Fastening
detail
Model
Motorfans
Dimensions
Coil connections
Drain connection
Net weight
Ø315 fan diameter unit
Model
Motorfans
Dimensions
Coil connections
Drain connection
Net weight
CGC 251E4R 251E4
251E6R 251E6
251E8R 251E8
n° x Ø mm 1x250 1x250
A [mm] 674 774
B [mm] 380 480
In [mm] 12.7 12.7
Out [mm] 12.7 12.7
Ø (GAS) 1" 1"
kg 14 16
CGC
n° x Ø mm
A [mm]
B [mm]
In [mm]
Out [mm]
Ø (GAS)
kg
Positioning of electric heaters
252G4 252E4 253G4
252G6 252E6 253G6
252G8 252E8 253G8
2x250 2x250 3x250
1224 1224 1674
930 930 1380
12.7 12.7 12.7
12.7 12.7 12.7
1" 1" 1"
24 26 33
Use thermostatic valve with external pressure equalizer
Fastening
detail
RBA - High power electric heater in coil
RBB - Low power electric heater in coil
RSA - High power electric heater on inner drip tray
311F4 312F4
311F6 312F6
311F8 312F8
1x315 2x315
874 1424
580 1130
12.7 12.7
12.7 12.7
1" 1"
22 37
Use thermostatic valve with external pressure equalizer
RBA - High power electric
heater in coil
RBB - Low power electric
heater in coil
RSA - High power electric
heater on inner drip tray
253E4 254G4 254E4
253E6 254G6 254E6
253E8 254G8 254E8
3x250 4x250 4x250
1674 2124 2124
1380 1830 1830
12.7 12.7 12.7
12.7 12.7 12.7
1" 1" 1"
36 42 46
Positioning of
electric heaters
313F4 314F4
313F6 314F6
313F8 314F8
3x315 4x315
1974 2524
1680 2230
12.7 12.7
12.7 (F8 15.87) 15.87 (F8 22.23)
1" 1"
52 67
33
