Reference standards and directives
- MACHINES DIRECTIVE 2006/42/EC
- LOW-VOLTAGE DIRECTIVE 2014/35/UE
- ELECTROMAGNETIC COMPATIBILITY DIR. 2014/30/UE
- PED DIRECTIVE 2014/68/UE
- ERP DIRECTIVE 2009/125/EC
- REFRIGERATING SYSTEMS AND HEAT PUMPS UNI EN 378
Proper access to model
Preliminary assembly
1. "EP" - "EP-ED" series: connect the heater and motors through entry
knockout "C"; to avoid possible damage to wires use the rubber fairlead
supplied separately with unit.
2. "EP/B" - "EP/B-ED" series: the heater and the motors are prewired in
junction box; use entry knockout "C" and rubber fairlead for all electric
connections.
Access/Repositioning
1. Use screws "A" to remove or reposition fan shroud.

Manufacturing and dimensional features

B
A
EP models
Dimensions A
(mm)
B
Inner coil connections In (SAE)
Out (SAE)
Drain connection ø mm
Net weight kg
( • ) Use thermal expansion valve with external pressure equalizer.
Fan shroud
Heater clip
200
170
80 81
460 460
310 310
1/2 1/2
1/2 1/2
16 16
6,4 6,4
Casing
Electric
heater
Drip tray
Fastening detail "F"
Positioning detail "R"
Heater clip
Heater
(•) 201
101
460 810
310 660
1/2 1/2
1/2 5/8
16 16
7,1 12,1
www.modinecoolers.com
(•) 301
1160
1010
1/2
5/8
16
16,8
