8.7 Technische Daten
BWT B57 und B60
Abmessungen in mm (inch)
BWT B57
F1
100 (3.94)
F3
30 (1.18) F 148 (5.83)
243 (9.57)
Typ Artikel-Nr.
Type Part No.
BWT B57x040 3457040
BWT B57x060 3457060
BWT B57x080 3457080
BWT B57x100 3457100
BWT B57x120 3457120
BWT B57x140 3457140
All manuals and user guides at all-guides.com
F2
F4
30 (1.18) F
F Kühlleistung
F Cooling
performance
113 mm 39 - 160 kW
4.45 in 52.3 - 214.5 hp
162 mm 74 - 232 kW
6.38 in 99.2 - 311.0 hp
211 mm 79 - 327 kW
8.31 in 105.9 - 438.3 hp
259 mm 84 - 424 kW
10.20 in 112.6 - 568.4 hp
308 mm 89 - 494 kW
12.13 in 119.3 - 662.2 hp
357 mm 93 - 566 kW
14.06 in 124.7 - 758.7 hp
BX340001, 10/2010
8.7 Technical Data
BWT B57 and B60
Dimensions given in mm (inch)
BWT B60
100 (3.94)
F1
F4
274,5 (10.81)
364 (14.33)
Ölanschluss Wasser-
anschluss
Oil ports*
Water ports*
wrench size
wrench size
F3, F1
F2, F4
SAE 2 ½ ** SAE 2 ½
SAE 2 ½ ** SAE 2 ½
SAE 2 ½ ** SAE 2 ½
SAE 2 ½ ** SAE 2 ½
SAE 2 ½ ** SAE 2 ½
SAE 2 ½ ** SAE 2 ½
Art. Nr. 34001
F2
F3
Gewicht Volumen
(Netto)
Volume
Net
Weight
39 kg 13 l
86 lb 3.4 gal
50 kg 20 l
110.2 lb 5.3 gal
61 kg 26 kg
134.5 lb 6.9 gal
73 kg 33 kg
160.9 lb 8.7 gal
84 kg 40 kg
185.2 lb 10.6 lb
95 kg 46 kg
209.4 lb 12.2 lb
