Bühler technologies BWT B05 Bedienungs- Und Installationsanleitung Seite 18

Bedienungs- und Installationsanleitung
Installation- and Operation Instruction
Öl / Wasserkühler BWT / oil / water cooler BWT
Typ Artikel-
Nr.
Type
Part No.
BWT B25x030 3425030
BWT B25x040 3425040
BWT B25x060 3425060
BWT B25x080 3425080
*Threads according to ISO 228
18
All manuals and user guides at all-guides.com
F Kühlleistung
F Cooling
performance
72 mm 13 - 45 kW
2.83 in 17.4 - 194.4 hp
94 mm 13 - 65 kW
3.74 in 17.4 - 87.1 hp
139 mm 20 - 90 kW
5.47 in 26.8 - 120.6 hp
184 mm 25 - 105 kW
7.24 in 33.5 - 140.8 hp
BX340001, 10/2010
Ölanschluss Wasser-
anschluss
Oil ports*
Water ports*
wrench size
wrench size
F3, F1
F2, F4
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
Art. Nr. 34001
Gewicht Volumen
(Netto)
Volume
Net
Weight
10,0 kg 2,0 kg
22.0 lb 0.5 lb
12,0 kg 3,0 kg
26.5 lb 0.8 lb
17,0 kg 5,0 kg
37.5 lb 1.3 lb
21,0 kg 7,0 kg
46.3 lb 1.8 lb
