Bedienungs- und Installationsanleitung
Installation- and Operation Instruction
Öl / Wasserkühler BWT / oil / water cooler BWT
Typ Artikel-Nr.
Type Part No.
BWT B60x040 3460040
BWT B60x060 3460060
BWT B60x080 3460080
BWT B60x100 3460100
BWT B60x120 3460120
BWT B60x140 3460140
*Threads according to ISO 228
** SAE-Anschlüsse in Druckstufe 3000 psi
**SAE flanges: CD 61
22
All manuals and user guides at all-guides.com
F Kühlleistung
F Cooling
performance
104 mm 30 - 113 kW
4.09 in 40.2 - 151.5 hp
147 mm 35 - 165 kW
5.79 in 46.9 - 221.2 hp
190 mm 40 - 216 kW
7.48 in 53.6 - 289.5 hp
232 mm 43 - 267 kW
9.13 in 57.6 - 357.9 hp
275 mm 56 - 301 kW
10.83 in 75.1 - 403.5 hp
318 mm 76 - 316 kW
12.52 in 101.9 - 423.6 hp
BX340001, 10/2010
Ölanschluss Wasser-
anschluss
Oil ports*
Water ports*
wrench size
wrench size
F3, F1
F2, F4
SAE 2 ½ ** SAE 2
SAE 2 ½ ** SAE 2
SAE 2 ½ ** SAE 2
SAE 2 ½ ** SAE 2
SAE 2 ½ ** SAE 2
SAE 2 ½ ** SAE 2
Art. Nr. 34001
Gewicht Volumen
(Netto)
Volume
Net
Weight
33 kg 9 kg
72.8 lb 2.4 lb
42 kg 13 kg
92.6 lb 3.4 lb
52 kg 17 kg
114.6 lb 4.5 lb
61 kg 22 kg
134.5 lb 5.8 lb
70 kg 26 kg
154.5 lb 6.9 lb
80 kg 31 kg
176.4 lb 8.2 lb
