Öl / Wasserkühler BWT / oil / water cooler BWT
8.5 Technische Daten
BWT B10, B12 und B25
Abmessungen in mm (inch)
BWT B10
F1 F2
F3 F4
27 (1.06)
F 72 (2.83)
119 (4.69)
Typ Artikel-
Nr.
Type
Part No.
BWT B10x020 3410020
BWT B10x030 3410030
BWT B10x040 3410040
BWT B10x050 3410050
BWT B10x070 3410070
BWT B10x090 3410090
BWT B12Hx060 3412060
All manuals and user guides at all-guides.com
BWT B12
F1 F2
F3 F4
63 (2.48)
119 (4.69)
F Kühlleistung
F Cooling
performance
49 mm 5 - 25 kW
1.93 in 6.7 - 33.5 hp
72 mm 10 - 40 kW
2.83 in 13.4 - 53.6 hp
94 mm 10 - 50 kW
3.70 in 13.4 - 67.0 hp
116 mm 15 - 60 kW
4.57 in 20.1 - 80.4 hp
161 mm 20 - 65 kW
6.34 in 26.8 - 87.1 hp
206 mm 20 - 80 kW
8.11 in 26.8 - 107.2 hp
145 mm 35 - 85 kW
5.71 in 46.9 - 113.9 hp
BX340001, 10/2010
8.5 Technical Data
BWT B10, B12 and B25
Dimensions given in mm (inch)
27 (1.06) F
Ölanschluss Wasser-
anschluss
Oil ports*
Water ports*
wrench size
wrench size
F3, F1
F2, F4
G1 41 mm G ¾ 36 mm
G 1 41 mm G ¾ 36 mm
G 1 41 mm G ¾ 36 mm
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
G1 ¼ 50 mm G1 41 mm
Art. Nr. 34001
BWT B25
F1 F2
F4
F3
72 (2.83)
119 (4.69)
Gewicht Volumen
(Netto)
Volume
Net
Weight
4,0 kg 1,0 l
8.8 lb 0.3 gal
5,0 kg 1,5 l
11.0 lb 0.4 gal
7,0 kg 2,0 kg
15.4 lb 0.5 gal
8,0 kg 3,0 kg
17.6 lb 0.8 gal
10,0 kg 3,5 kg
22.0 lb 0.9 lb
13,0 kg 4,0 kg
28.7 lb 1.1 lb
13,5 kg 4,3 kg
29.8 lb 1.1 lb
17
