Strobe effect
In FLAS mode the speed for strobe effect can be set.
1 Press the MENU button so many times until FLAS is indicated in the display Confirm with the ENTER
2 Use the buttons UP and DOWN to adjust the desired speed (FL0-9). Confirm with the ENTER button.
Behavior at missing DMX-signal
In DMX lost mode the program offers different options when no DMX signal is received.
1 Press the MENU button repeatedly until the display shows the DMX lost menu. Confirm with the ENTER
button.
2 Select the desired program with the UP and DOWN buttons (see menu structure). Confirm with the
ENTER button.
Interconnecting several devices (master/slave operation)
Several devices may be interconnected (max. 32). Then all slave units can be synchronized and controlled
with the master unit without the need for a DMX controller. The devices must be set to the corresponding
operating modes.
1 Configure all slave units before connecting the master unit: Press the MENU button so many times until
SLAU is indicated in the display. Confirm with the ENTER button.
2 Connect the DMX output of the master unit to the DMX input of the first slave unit. Then connect the
DMX output of the first slave unit to the DMX input of the second slave unit, etc. until all units have been
connected in a chain. Make sure the master unit is the first in the chain. Do not connect a DMX controller
to the DMX input of the master unit.
3 Set the master unit to the desired operating mode. The interconnected devices will now operate in sync.
Potentiometer
If you select "on" in the PotE menu item, the brightness and color temperature rotary controls are activated.
When set to "oFF", they are disabled.
Quick access via rotary knob:
The brightness and color temperature can be controlled via the rotary controls on the back of the device (see
device overview), thus providing quick access to the static settings.
PWM (Pulse-width modulation)
In the menu rEFr the PWM frequency off the LEDs can be set.
1 Press the MENU button repeatedly until the display shows the rEFr menu. Confirm with the ENTER
button.
2 Select the desired PWM frequenzy (900-25kHz) with the UP and DOWN buttons. Confirm with the
ENTER button.

DMX operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 6 control channels.
However, it can also be switched to a mode with 2 or 4 channels if different functions are required. To be
able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the MENU button so many times until Addr is indicated in the display. Confirm with the ENTER
button.
2 The display indicates 2 CH (2 DMX channels), 4 CH (4 DMX channels) or 6 CH (6 DMX channels). Use
the buttons UP and DOWN to select the desired number of DMX channels. Confirm with the ENTER
button.
3 Now the display indicates the menu item for the DMX start address d***. Use the buttons UP and DOWN
to set the address. Confirm with the ENTER button.
4 The display will not blink when DMX signals are being received. If no control signals are available, the
display will blink.
