OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any
commercial DMX controller as well as wireless via QuickDMX with the optional available EUROLITE
QuickDMX USB Wireless Transmitter/Receiver.

Menu structure

Mode
DMX mode
Static white color
Automatic mode
Sound control
Running speed in
automatic and sound-
controlled mode
Microphone sensitivity for
sound control
White color setting
Color temperature
Dimmer
Strobe effect
Sound control silent scene
Behavior in case of
missing DMX signal
Slave mode
Potentiometer
PWM (pulse-width
modulation)
Firmware version
Display
6CH
Addr 4CH
2CH
Stat S 01-3
Auto Au 1 - 3
Soun So 1 - 3
SPEE SP 1-9
SEnS SE 1-9
U000-255
Colo
C000-255
tEMP 2800-6500
diMM dI 1-dI 9
FLAS FL0-9
on
SILE
oFF
Blac
Hold
Lost Full
Stat
auto
SLAV Slave
on
PotE
oFF
rEFr
900-25kHz
Vx.x Vx.x
25/32
d001-512 6-channel mode and start address
d001-512 4-channel mode and start address
d001-512 2-channel mode and start address
Constant lighting in one of 3 white
colors
Auto program
Sound program
Program running speed
slow > fast
Microphone sensitivity
low > high
Warm white 0-100%
Cold white 0-100%
2800-6500K
Total brightness
dark > bright
Strobe effect
slow > fast
LEDs off if there is no music signal
LEDs remain on if there is no music signal
LEDs switched off
Most recent DMX value is held
All LEDs light at 100% brightness
Last selected static white color (1-3)
Last selected auto program (1-3)
Slave mode
Switching on the manual rotary
controls
Switching off the manual rotary
controls
PWM (pulse-width modulation)
Firmware version number
Function
00136914, Version 1.0
