PROTECTING THE ENVIRONMENT
Disposal of old equipment
When to be definitively put out of operation, take the product to a local recycling plant for a
disposal which is not harmful to the environment. Devices marked with this symbol must not be
disposed of as household waste. Contact your retailer or local authorities for more information.
Remove any inserted batteries and dispose of them separately from the product.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Protection class:
IP classification:
Power connection:
Power output:
Lamp type:
LED:
Color temperature:
Fuse:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Color rendering index (CRI) more than:
Beam angle (1/2 peak):
Flash rate:
Housing color:
Display type:
Dimensions:
Weight:
100-240 V AC, 50/60 Hz
40 W
I
IP20
IEC connector (M) mounting version Power supply
cord with safety plug
IEC connector (F) mounting version
LED lamp
84 x SMD 2835 0.5W WW
84 x SMD 2835 0.5W CW
2800K - 6500K adjustable
T1A
2; 4; 6
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
Passive convection
Stand-alone; DMX; QuickDMX via USB (optional);
CRMX by LumenRadio (optional); W-DMX by
wireless solution (optional); Master/slave function;
Sound to light via Microphone
80 Ra
120°
0 – 20 Hz
Black
4 digits 7-segment LED display
Width: 28.1 cm
Depth: 11.0 cm
Height: 17.3 cm
1.70 kg
30/32
00136914, Version 1.0
