LED PLL-168 CW/WW Panel
DANGER! Electric shock caused by short-circuit
Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires. Never open the housing. Keep the device away from rain and
moisture.
Please read these instructions carefully before using the product. They contain important
information for the correct use of the product.
Every person involved with the installation, operation and maintenance of this device has to
- be qualified
- follow the instructions of this manual
- consider this manual to be part of the total product
- keep this manual for the entire service life of the product
- pass this manual on to every further owner or user of the product
- download the latest version of the user manual from the Internet

INTRODUCTION

Thank you for having chosen one of our products. If you follow the instructions given in this manual, we are
sure that you will enjoy this device for a long period of time.

Product features

DMX controlled surface light with 84 LEDs each in cold and warm white, QuickDMX port and barn
doors
• High-grade surface light with 168 super bright, white LEDs
• 168 x SMD 2835 0,5 W LED in CW and WW for dynamic strobe effects and surface light
• Wide beam angle of 120°
• Color temperature steplessly adjustable between 2800 K and 6500 K
• Ideal for photography, film, stage and trade fair lighting
• Energy saving, durable and environmental friendly
• Auto, music, master/slave and DMX mode
• Built-in auto and music show programs
• Color temperature and brightness manually adjustable via rotary control
• Variable PWM frequency (pulse-width modulation)
• Strobe effect
• Addressing and setting via control panel with 4-digit LED display
• Sound-control via built-in microphone with adjustable microphone sensitivity
• Supports QuickDMX - the wireless DMX system from Eurolite
• Compatible with CRMX by LumenRadio und WDMX by Wireless Solution
• Built-in phantom-powered USB port for QuickDMX, CRMX and WDMX receivers (optional)
• 2, 4 or 6 DMX channels selectable
• 4 barn doors to avoid blinding the audience and for protection during transport
• Flicker-free projection
• Slim, rugged metal housing
• Swivel mounting bracket for ceiling or wall mounting
• IEC terminals for power linking up to 8 units
• Switch-mode power supply for operation between 100 and 240 volts
USER MANUAL
18/32 00136914, Version 1.0
