i) Measuring temperature
During the temperature measurement, expose only the temperature sensor to the
temperature to be measured. The operating temperature of the measuring device
must not be above or below the permissible range, because this can result in
measuring errors.
The contact temperature probe may only be used on voltage-free surfaces.
All K-type thermosensors can be used to measure temperature. The temperature is displayed in °C
and °F. The temperature probe included in delivery is designed for measurements between -40 to
+400 °C. Optional sensors can be used for the complete measuring range (-40 to +1000 °C).
For measuring temperatures, proceed as follows:
1. Turn on the DMM and select the measurement range "°C".
2. Press the SHIFT/SETUP button (3) to switch to a display in °F.
3. Insert the thermosensor with the correct polarity with the plus
pole in the °CHzVΩ measuring socket (7) and the minus pole
in the COM measuring socket (8) (Fig. 9).
4. The temperature appears in the main display in °C or °F,
depending on the pressing of the SHIFT/SETUP button.
5. If "OL." appears in the display, the measuring range (-40 to
+1000 °C) has been exceeded.
6. After the measurement has been completed, remove the
sensor and turn the DMM off.
When the measuring input (sockets: °CHzVΩ – COM) is bridged, the device temperature of
the DMM is displayed. The temperature adjustment to the environment is very slow due to the
sealed housing.
Fig. 9
